Specifications:
- Input: 120 VAC 50/60 Hz (default) or 230 VAC 50/60 Hz (by internal jumper setting)
- Output: 24 VDC
- Current: 40 A
- Remote Control: 900-RC
- Weight: 9 lb (4.1 kg)
- Dimensions: 15 × 9.61 × 3.82 in (381 × 244 × 97 mm)
- Safety: Intertek ETL Listed to meet UL Standard UL-1564, EMI compliant to FCC Part 15(B), Class B
Features:
- Switch mode technology for high efficiency lightweight and quiet operation
- Automatic operation for flooded AGM and gel cell lead acid batteries
- Charges two battery banks simultaneously with no isolator needed
- Works as a battery charger power supply or DC UPS
- User configurable AC input for 120 or 230 VAC at 50 or 60 Hz
- User-selectable 2 or 3 stage charging via DIP switch
- Half Power Mode for safe charging of lower capacity batteries
- Built-in voltmeter and ammeter for real-time monitoring
- Smart fan cooling based on output current
- Short circuit and overload protection
- Reverse battery connection and over-temperature protection
- Included a temperature sensor for accurate charging in varying conditions
