Pytes HV48100 Series Battery Control Unit

Stay Powered, Stay Happy with Pytes HV48 Lithium Ion Battery

The Pytes HV48100 Series Battery Control Unit is a high-efficiency lithium module designed for reliable home or commercial energy storage, with a 4.8 kWh capacity and smart BMS protection. It features fast communication ports, strong cycle life, flexible rack mounting, and stable performance even during heavy daily use.

Bring powerful, dependable energy storage to your space today with the Pytes HV48100 High-Voltage Lithium Ion Battery - 151201100050. Upgrade your setup now and enjoy consistent power when you need it most.

Features

• High voltage 48V design for efficient energy management
• Real-time monitoring for continuous system control
• Modbus communication support for easy integration
• Fast 2-hour full charging capability
• Advanced system features and functions for smoother operation
• Continuous monitoring and control of battery status and energy flow
• Built-in fault diagnosis for early detection of issues
• Reliable performance designed to enhance overall system stability

Specifications

• Controller Working Voltage: 200V to 870V
• Self-consumption Power: 7.56W
• Dimensions (WDH): 484510140 mm / 19.120.15.5 in
• Weight: 13 kg / 28.7 lbs
• Communication: CAN, RS485, Dry Contact, WiFi
• Cell Type: LFP
• Nominal Energy: 5.12 kWh
• Nominal Voltage: 51.2V
• Nominal Capacity: 100Ah
• Continuous Discharging/Charging Current: 50A DC
• Voltage Range: 45.5 to 58V
• Depth of Discharge: 80 percent
• Dimensions (WDH): 484530140 mm / 19.120.95.5 in
• Weight: 43 kg / 94.8 lbs
• Communication: CAN, RS485
• Cycle Life: ≥6000 cycles
• Operation Temperature: -20°C to 60°C / -4°F to 140°F
• Storage Temperature: -30°C to 60°C / -22°F to 140°F
• System Energy: 5.12kWh * n
• System Voltage: 51.2V * n
• System Capacity: 100Ah
• Charge Upper Voltage: 58V * n
• Discharge Lower Voltage: 45.5V * n
• Continuous Discharging/Charging Current: 50A DC
• BCU Model: HV48100 BCU
• BMU Model: HV48100 BMU
• BMU Qty (Optional): 5 to 15
• Depth of Discharge: 80 percent
• Dimensions (WDH): 6006401555 mm / 23.625.261.2 in
• Weight: 89.6 kg + 13 kg + 43 kg * n
  197.5 lbs + 28.7 lbs + 94.8 lbs * n
• Communication: CAN, RS485, Dry Contact, WiFi
• Cycle Life: ≥6000 cycles
• Operation Temperature: -20°C to 60°C / -4°F to 140°F
• Storage Temperature: -30°C to 60°C / -22°F to 140°F
• Operation Humidity: 0 to 95 percent, no condensation
• Protection Level: IP20
• Certification: CE, IEC62619, UL1973, UN38.3, UL9540 (TBD), UL9540A (TBD)

Product Documents

• Data Sheet
• User Manual
• Sol-Ark Integration Guide
• Phocos Integration Guide
• Victron Integration Guide
