Symo Advanced Lite Turns Sunlight Into Pure Clean Energy
Fronius Symo Advanced Lite Inverter - 15.0kW delivers reliable solar energy conversion with high efficiency, flexible system design, and smart monitoring features that make managing home power simple. It offers excellent performance in partial shading, strong grid support functions, and durable construction built for long-term use.
Bring clean power into your home with the Fronius Symo Advanced Lite - 4,210,052,841 and enjoy smooth, consistent energy every day. Shop now and take advantage of a smarter way to power your indoor life.
Features
- Dual MPPT inputs for maximum energy harvesting
- Built-in AFCI protection for enhanced system safety
- Wide power range from 10.0 to 24.0 kW for flexible system design
- SnapINverter mounting system with NEMA 4X enclosure for easy installation
- WiFi Ethernet and Serial monitoring with a preinstalled Datamanager Card
- Full monitoring access through the Fronius Solar.Web platform
- Standard 10-year warranty extendable to 20 years for long-term confidence
- UL and CSA certified for trusted safety and performance
- SuperFlex Design enabling optimal performance on complex rooftops
- Dynamic Peak Manager and Arc Guard technology for efficient, safe, and reliable energy production
Specifications
- Continuous AC power output of 15,000W
- Operating voltage range 325V to 1000V
- Works with 208V or 240V grids at 60 Hz
- Best paired with up to 19,500W of solar panels
- Transformerless, 3 phase design for high efficiency
- Maximum DC input voltage 1000VDC and max DC input current 75A
- Peak efficiency of 97.3 percent and CEC efficiency of 96.5 percent
- Includes 1 MPPT with a voltage range of 325V to 850V
- Has 6 positive and 6 negative input channels
- Rated NEMA 4X for outdoor durability
- Mounts on DIN rail, rack, or surface
- Special features include WiFi capability, field serviceability, and flexible system design
General Information
- Type: String inverter
- Safety and performance approvals: UL 1741, UL1998, IEEE 1547, IEEE 1547.1, ANSI/IEEE C62.41, FCC Part 15 A and B, NEC 2014 690, CSA C22.2 No. 107.1, UL1699B, and CSA TIL M-07
