Dimensions and Weight
- Size: 511 mm (W) x 724 mm (H) x 226 mm (D)
- Weight: 41.68 kg
Installation
- Suitable for indoor and outdoor use
- Works at tilt angles from 0 to 90 degrees
- Fronius Shade Cover required for angles below 15 degrees
Environmental Ratings
- Humidity: 0–100 percent non-condensing
- Protection rating: NEMA 4X
- Cooling: Variable speed fan
- Max elevation: 2000 m at 1000 V or 3400 m at 850 V
- Night consumption: Under 1 W
Design and Safety
- Transformerless inverter
- Advanced safety features including AFCI, ground fault protection, rapid shutdown, and over-temperature protection
- DC disconnect included
- Certified to major standards including UL 1741, IEEE 1547, FCC Part 15, and NEC 2017
Connections and Interfaces
- DC terminals: 6 DC+ and 6 DC
- AC terminals: 14–6 AWG screw terminals
- USB port for updates and data logging
- 2x RS422 ports for Solar Net
- Wi Fi, Ethernet, and Modbus (TCP and RTU)
- Supports SunSpec Rapid Shutdown PLC
- Compatible with Tigo TS4 F (pending testing)
- Includes 6 inputs and 4 digital I/Os for load control and signaling
Performance and Electrical
- MPPT inputs: 2
- Recommended PV size: 8.0 to 13.0 kWp
- Max input current: 41.5 A
- Short circuit limit: 62.2 A
- Voltage range: 200–600 V
- MPP range: 300–500 V
- Max input voltage: 600 V
- Output voltage: 208–240 V three phase
- Max output power: 9995 W at 208 or 240 V
- Output current: 24.0 A at 240 V or 27.7 A at 208 V
- Frequency: 45–66 Hz
- Nominal frequency: 60 Hz
- THD: Under 1.5 percent
- Breaker size: 35 A for 208 V
- Max efficiency: 97 percent
- CEC efficiency: 96.5 percent (208 and 240 V)
