Input
- Works with 4.8 to 9.3 kW of solar panels
- Two MPPT trackers that each support up to 18 A of input current
- Total DC current capacity of 36 A
- Handles up to 22.5 A short circuit current per MPPT
- Operates from 80 to 600 V, with 600 V max input
- Ideal input voltage is 420 V
- Accepts DC wiring from AWG 14 to AWG 6
Output
- Maximum output power: 6000 W
- Continuous output current: 28.8 A at 208 V or 25 A at 240 V
- Recommended breaker size: 40 A (208 V) or 35 A (240 V)
- CEC efficiency: 96 percent
- Peak efficiency: 96.9 percent
- AC wiring range: AWG 14 to AWG 6
- Grid compatible with 208 or 240 V at 60 Hz
- Harmonic distortion under 5 percent
- Adjustable power factor from 0.85 to 1
General
- Size: 16.9 in x 24.7 in x 8.1 in
- Weight: 47.29 lb
- Weather rating: NEMA 4X for indoor or outdoor use
- Uses under 1 W at night
- Transformerless design with variable speed fan cooling
- Works in temperatures from -40°F to 131°F
- Supports 0 to 100 percent humidity
- Includes multiple DC and AC screw terminals for easy wiring
- Fully certified for US and Canadian electrical standards
Connectivity and Safety
- Built-in AFCI and DC disconnect for added safety
- WiFi, Ethernet, and Modbus communication supported
- Remote monitoring through Fronius Solar.web
- USB port for updates or data logging
- RS422 ports for Fronius Solar Net networking
- Built-in datalogger and web server
