Electrical Performance
- Two MPP trackers for flexible solar panel setup
- Maximum PV input power: 8000 W
- Starts feeding power at 80 V
- MPP operating range: 260 V to 480 V
- PV Point backup switches over in up to 22 seconds
- Full Backup switches over in up to 17 seconds
- Works with 50 Hz or 60 Hz grids
Size and Weight
- Length: 583 mm
- Width: 529 mm
- Height: 583 mm
- Depth: 180 mm
- Weight: 20.85 kg
- Weight with packaging: 25.9 kg
Design and Durability
- Transformerless inverter for high efficiency
- Active Cooling Technology to protect internal components
- Suitable for indoor or outdoor installation
- Operates from -40°C to 60°C
- Protection class: 1
- Overvoltage category: DC category 2 and AC category 4
Connection Options
- DC PV terminals: multiple spring-type copper connections
- Battery terminals: spring-type copper (AWG 12-8)
- AC terminals: copper or stranded wires (AWG 12-6)
- Backup power terminals: AWG 16-8
Backup and Safety Features
- PV Point backup function included
- Noise level: 51 dB(A)
- Interference emission class B
- Built-in DC insulation monitoring
- Overload protection with automatic power adjustment
- Integrated DC disconnector
- Reverse polarity protection
- Arc fault protection with Fronius Arc Guard
