Input & PV Performance
- 2 MPP trackers
- Max PV input power: 10.36 kW
- Max PV generator power: 15 kWpeak
- Voltage range: 65 to 600 V
- MPP operating range: 260 to 480 V
- Max input current: 22 A per tracker
Output & AC Performance
- AC output: 10 kW
- Max AC current: 45.5 A
- Voltage: 220/230 V
- Frequency: 50/60 Hz
- Power factor: 0.8 to 1
Backup Power (PV Point)
- Backup output: 3000 VA
- Switchover time: 20 seconds
- Backup frequency: 53 Hz
Battery Compatibility
- Max battery power: 10.36 kW
- Battery voltage range: 150 to 455 V
- Compatible with BYD Battery Box Premium HVS/HVM and LG RESU FLEX
General Specs
- Dimensions: 595 × 529 × 180 mm
- Weight: 21 kg
- Protection rating: IP66 (indoor or outdoor)
- Operating temperature: -40°C to +60°C
- Max altitude: 4000 m
- Cooling: Active air cooling
- Sound level: 51 dB
Efficiency
- Max efficiency: 97.3%
- European efficiency: up to 97.0%
- MPP efficiency: 99.74%
Protection & Safety
- Built-in DC disconnector
- Reverse polarity protection
- Overload protection
- DC insulation monitoring
Connectivity & Smart Features
- WLAN and Ethernet
- Solar.web monitoring
- Modbus TCP & RTU
- Integrated datalogger
- Digital inputs/outputs for energy management
Backup Functions
- PV Point basic backup support
- Full Backup available with a compatible battery
