Solar Input
- Max DC input per MPPT: 12,000W
- Max PV input power: 21,000W
- Max PV power to battery and AC: 18,000W
- DC voltage range: 100V to 600V
- Nominal DC voltage: 360V
- Full power MPPT range: 230V to 500V
- Max DC current: 25A / 15A / 15A
- MPPTs: 3 total with 2 / 1 / 1 strings
AC Input and Output (Grid)
- Continuous AC power to grid: 12,000W at 240V
- Continuous AC power to loads with grid or generator: 48,000W at 240V
- Output voltage options: 120/240V split phase, 120/208V split phase, 120/208V three phase
- Max continuous AC current: 50A at 240V
- AC frequency: 50Hz / 60Hz
Off-Grid Output
- Max output power: 12,000W at 240V
- Voltage options: 120/240V split phase, 120/208V split phase, 120/208V three phase
- Output frequency: 50Hz / 60Hz
- Output current: 50A at 240V or 208V
- Peak power: 14kW (10 min), 16kW (5 min), 20kW (500ms)
- Switching time: Seamless
Battery
- Battery types: Lithium and Lead Acid
- Nominal battery voltage: 48V
- Battery voltage range: 48V to 56V
- Max charge/discharge current: 250A
- Max charge/discharge power: 12,000W
Efficiency
- MPPT efficiency: 99.9%
- Max efficiency: 97.5%
- CEC efficiency: 96.5%
Protection
- Anti-islanding protection: Yes
- DC switch: Yes
- Ingress rating: NEMA 4X, IP65
- Surge protection (SPD): Yes
- AFCI: Optional
- Rapid shutdown: Built in APsmart transmitter
General
- Dimensions: 31.1 x 20.5 x 10.4 in (790 x 520 x 264 mm)
- Weight: 127 lbs (58 kg)
- Display: Color LCD
- Temperature range: -20 to 60°C (-4 to 140°F)
- Cooling: Fan
- Communication: RS485, Wi Fi, CAN
Certifications
- UL1741, UL1741SB, IEEE1547A, Rule 21, ISO NE, FCC Class B, HECO, CEC, Luma, SGIP, NOM
Warranty
- 10 years
