DC Input (Solar)
- Max solar input per MPPT: 6000W each
- Total max PV input power: 13000W
- Max PV power to battery and AC: 12000W
- DC voltage range: 100V to 600V
- Nominal DC voltage: 360V
- MPPT operating range: 170V to 500V
- Max DC input current: 25A per MPPT
- Number of MPPTs: 2
AC Input and Output (Grid Mode)
- Continuous AC power to grid: 8000W at 240V
- Continuous AC passthrough to loads: 21000W at 240V
- Generator passthrough: 12000W at 240V
- Output voltage: 120V and 240V
- Max continuous AC current: 33.3A at 240V
- Frequency: 50Hz or 60Hz
AC Output (Off Grid)
- Max off grid output: 8000W
- Output voltage: 120V and 240V
- Frequency: 50Hz or 60Hz
- Continuous output current: 33.3A at 240V
- Peak power: 16000W for 500ms
- Transfer switching: Seamless
- Auto start generator port: 50A / 12kW
Battery Details
- Compatible batteries: eVault Max, eFlex, LFP 10 Max
- Nominal battery voltage: 48V
- Battery voltage range: 48V to 56V
- Max charge/discharge current: 167A
- Max charge/discharge power: 8000W
Efficiency
- MPPT efficiency: 99 percent
- Max inverter efficiency: 97 percent
- CEC efficiency: 96 percent
Protection
- Anti-islanding: Yes
- DC switch: Yes
- Protection rating: NEMA 4X and IP65
- Surge and fault protection: SPD and AFCI
- Rapid shutdown: Built-in APsmart transmitter
General Information
- Size: 580 × 490 × 265 mm (22.8 × 19.3 × 10.4 in)
- Weight: 44 kg (97 lbs)
- Display: Color LCD touch screen
- Operating temperature: -25 to 60°C (-13 to 140°F)
- Cooling: Fan-cooled
- Communication: RS485, Wi Fi, CAN
Certifications
- UL1741, UL1741SB, IEEE1547A, Rule 21, ISO NE, FCC15 Class B, HECO, CEC, Luma
Warranty
- 5-year warranty with an optional 10-year upgrade
