Electrical
- Nominal Voltage: 51.2 V
- Energy: 16.08 kWh
- Capacity: 314 Ah
- Charge Voltage (Bulk/Absorption): 55.2 to 56.8 V
- Float Voltage: 53.6 V
- Charge Termination Current: 5 A
- Recommended Low Voltage Disconnect: 48 V
- Minimum Low Voltage Disconnect: 43.2 V
- Max Continuous Charge Current: 200 A
- Max Continuous Discharge Current: 200 A
- Peak Discharge (15 seconds): 300 A
- Self Discharge (On): ≤ 25 mA
- Self Discharge (Off): ≤ 4 mA
- Breaker: 200 A single pole
- Short Circuit Fault Current: 7.16 kA / 3.58 kA
- Arc Flash Energy: 0.310 Cal/cm²
- Arc Flash Boundary: 239 mm (9.41 in)
Mechanical
- Height: 900 mm (35.43 in)
- Width: 465 mm (18.31 in)
- Depth (Body): 247 mm (9.72 in)
- Depth with Bracket: 271 mm (10.7 in)
- Terminal Type: Quick-connect plug and pull
- Weight: 136 kg (299.83 lb)
- IP Rating: IP65
- Case Material: Galvanized steel
- Certifications: UN38.3, UL 1973, UL 9540A, UL 9540 DC ESS 3rd Edition Pending
