FEATURES
Longevity of service
IP65 waterproof and dustproof
Flame retardant rating: UL94 V-0 (Plastic shell)
Green energy without metal contaminants
Extremely high number of charge/discharge cycles
Lightweight, small size
Extreme performance safety tested to guarantee safety under extreme conditions€”no fire, explosion, or leakage.
Sophisticated Battery Management System (BMS)
BATTERY
Cell Type:
LiFePO4 Battery
Nominal Voltage:
12.8V
Nominal Capacity:
300Ah
Nominal Energy:
3840Wh
Cycle Life:
4000 cycles
Maximum Expansion (Parallel & Series):
4P4S
BMS
BMS:
300A
Maximum Charging Current:
300A
Maximum Continuous Discharge Current:
300A
CHARGE
Charge Method:
CC/CV
Charge Voltage:
14.4V ± 0.2V
Recommended Charge Current:
150A
TEMPERATURE
Charge Temperature:
32„‰ to 131„‰ (0„ƒ to 55„ƒ)
Discharge Temperature:
-4„‰ to 140„‰ (-20„ƒ to 60„ƒ)
Storage Temperature:
50„‰ to 95„‰ (10„ƒ to 35„ƒ)
OTHERS
Net Battery Weight:
71.3lb
Size(L*W*H):
20.47x10.55x8.66in
Housing Material:
ABS (Flame Retardant Plastic)
Protection Class:
IP65
Warranty:
5 Years
