Victron Energy QUA125021100 Quattro 12/5000/220-100/100 120V Inverter/Charger Overview
The Victron Energy Quattro 12/5000/220-100/100 120V Inverter/Charger is a versatile, high-performance power solution designed for demanding applications. Combining a pure sine wave inverter and adaptive battery charger, the Quattro is engineered for off-grid power systems, marine setups, RV applications, and backup energy solutions. Its dual AC inputs allow seamless switching between two independent power sources, such as shore power and a generator, ensuring uninterrupted energy supply.
The Quattro’s advanced features, including PowerAssist technology, parallel operation, and remote monitoring capabilities, make it a reliable choice for large and complex systems. It offers scalability for increased power output or system redundancy, ensuring optimal performance in any scenario.
Features of Victron Energy Quattro 12/5000/220-100/100
Dual AC Inputs for Seamless Power Management
- Automatically switches between two independent AC sources (e.g., shore power and generator) for uninterrupted power supply.
PowerAssist Technology
- Prevents overloads by automatically reducing battery charging and supplementing power output with stored energy when needed.
Uninterrupted Power Supply
- Ensures a smooth 20-millisecond switch from external power to the internal inverter during outages, maintaining continuous operation for connected devices.
Scalability and Parallel Operation
- Connect up to six Quattro units in parallel for higher power demands.
- Supports three-phase and split-phase configurations for flexible system designs.
Remote Monitoring and Control
- Compatible with GX devices like Cerbo GX for global system monitoring and control via the VRM app or portal.
- Enables settings adjustments, performance tracking, and automatic generator starts from anywhere in the world.
Specifications
| Feature |
Details |
| Model Number |
QUA125021100 |
| AC Input Voltage |
120V |
| DC Input Voltage |
9.5-17V |
| Output Voltage |
120VAC/60Hz |
| Continuous Power Output |
5000VA |
| Max Battery Charge Current |
220A |
| AC Input Current (Dual) |
100A per input |
| Weight |
72 lb |
| Dimensions (H x W x D) |
22 x 13 x 10 inches |
What's in the Box
-
1 x Victron Energy Quattro 12/5000/220-100/100 120V Inverter/Charger
Warranty
-
5-year limited warranty with an option to extend to 10 years for an additional fee.
- Battery warranty details:
-
Lead-acid and AGM batteries: 2 years.
-
Lithium batteries: 3 years.
Applications
The Victron Energy Quattro 12/5000/220-100/100 is ideal for:
-
Off-grid solar energy systems.
-
Marine and RV energy solutions.
-
Commercial and industrial backup power setups.
- Systems requiring dual AC inputs and uninterrupted energy management.
Why Choose Victron Energy Quattro?
The Victron Energy Quattro offers unmatched flexibility, scalability, and reliability, featuring dual AC inputs, PowerAssist technology, and advanced remote monitoring. Certified for robust performance, it’s the ultimate choice for powering complex systems in various applications.
