Sol-Ark 60 kWh Indoor Lithium Battery System

Silent. Smart. Strong. That’s the Sol-Ark L3-Hv-60KWH Indoor Battery Bank

Sol-Ark 60 kWh Indoor Lithium Battery System is a high-capacity, all-in-one energy storage system built for reliable indoor use. It offers 60 kWh of lithium iron phosphate (LiFePO₄) power, ensuring long life, safety, and high efficiency. With modular scalability, advanced battery management, and quiet operation, it delivers seamless backup power and energy independence for both homes and businesses.

Stay powered without interruptions. Get the Sol-Ark 60 kWh Indoor Lithium Battery System - L3-HV-60KWH today and experience smart, sustainable energy at its best.

Features

• Prismatic cells for maximum reliability, efficiency, and safety
• Automatic battery and BMS configuration
• Built-in fire suppression in every 5kW pack
• Modular design for easy parallel or series expansion
• Optional USB and Wi-Fi upgrade support
• Remote monitoring and firmware upgrades
• High energy density with long-lasting LiFePO₄ technology
• Seamless integration with Sol-Ark inverters
• Quiet and maintenance-free indoor operation
• Backed by a 10-year warranty for peace of mind

Specifications

• Cell Chemistry: LiFePO4
• Module Energy: 5.12kWh
• Module Nominal Voltage: 51.2V
• Module Capacity: 100Ah
• Battery Module Qty In Series (Optional): 12
• System Nominal Voltage: 614.4V
• System Operating Voltage: 499.2 ~ 700V
• System Energy: 61.44kWh
• System Usable Energy: 55.29kWh
• Charge/Discharge Current: Recommend: 50A, Nominal: 100A,
• Peak Discharge: 125A
• Communication Port: CAN2.0/RS485
• IP Rating of Enclosure: IP20
• Dimension (Inches): 23.19 in (W) × 23.2 in (D) × 88.19 in (H) (58.9 cm × 59.0 cm × 224.0 cm)
• Weight Approximate: 3,053 lb (1384.5 kg)
• Certification: CE, IEC62619, VDE2510-50, UL1973, UL9540A, UN38.3, UL9540
• Warranty: 10 Years

Product Documents

• Brochure
• Overview
• Data Sheet
• Installation Guide
