The Samlex EVO-4024E is a 4000 Watt pure sine wave inverter, 110 ADC battery charger, and 40 Amp transfer relay in a single unit, designed for international use. It provides 230 VAC output at 50/60 Hz and is CE marked for export.
Product features
Pure sine wave output: Supplies clean and stable power suitable for sensitive electronics like computers and medical equipment.
Integrated components: Combines an adaptive 4-stage battery charger and a 40A transfer relay with the inverter.
Advanced charging: An adaptive battery charging algorithm adjusts the charging process based on the battery's condition to prolong its lifespan. It supports equalization mode for manually initiating an extended charge.
Dual AC inputs: Allows for the simultaneous connection of two separate AC sources, such as grid power and a generator.
High surge capacity: The inverter is capable of handling significant startup surges, providing up to 6000 watts of power for 5 seconds.
Optional remote control: The EVO-RC remote control (sold separately) offers real-time monitoring and programmable features, including data logging for performance analysis.
Built-in safety: The unit has "Bullet-Proof Intelligence" with nine points of physical protection that are monitored thousands of times per second to detect and prevent damage from adverse conditions.
Temperature management: Two internal fans are speed-controlled by five temperature sensors, reducing fan noise and energy consumption.
Wide operating temperature: The unit can operate in a broad temperature range from -20°C to +60°C.
Corrosion resistance: Conformally coated circuit boards protect against corrosion in high-humidity or marine environments.
"Online Mode": This feature prioritizes using the battery/inverter over the grid, making it ideal for systems that primarily run on solar power.
Specifications
According to DonRowe.com and SamlexAmerica.com, here are the key specifications for the Samlex EVO-4024E:
Feature Specification
Inverter Continuous Power 4000 VA (17.4 A)
Input DC Voltage 24 VDC
Output AC Voltage 230 VAC, 50/60 Hz
Peak Surge Power (5 sec) 6000 W (26.1 A)
Charger Input AC 230 VAC, 50 Hz
Charger Output DC 110 ADC, 24 VDC
Transfer Relay 40 A
Inverter Weight 64 lbs (29 kg)
Dimensions (L x W x H) 16.8" x 12.8" x 8.1" (426 x 325 x 207 mm)
