Discover Energy Hybrid Inverter/Charger, 8600 Watt High Voltage 120/240VAC w/12900 Watt, 90 - 550 VDC MPPT

Discover Energy Hybrid Inverter/Charger, 8600 Watt High Voltage 120/240VAC w/12900 Watt, 90 - 550 VDC MPPT

SKU H2-8.6K-S3-US
$2,293.20

Notify me when back in stock

✅ FREE REPLACEMENT PARTS FOR LIFE ⚙️

¡También ofrecemos atención al cliente en español!

Find a better price somewhere else?

Well... we will BEAT their price to get you the lowest pricing, we will find and SPEAK with a local installer, AND you get our post-purchase customer support.

Call/Text Us: 1-888-855-7286
Live Chat With an Expert

  • US Based Authorized DuroMax Dealer

    Full manufacturer warranty included

  • 4-5 Day Free Shipping + No Sales Tax

    More savings on every purchase and ships in 4-5 business day

  • Easy 30-Day Returns & Price Beat Guarantee

    Risk-free shopping + best price guaranteed

  • Post-Purchase Customer Support

    Dedicated help whenever you need it


ESTIMATED DELIVERY BETWEEN

Order within to get it by the earliest date.


Discover Energy Systems H2-8.6K-S4-US H2 HV Split Phase Hybrid Inverter. It is a versatile hybrid inverter designed for residential and small commercial solar installations, capable of integrating solar energy, battery storage, and grid power.
 Key specifications
 According to the official Discover Energy Systems documents and reseller sites like NAZ Solar Electric, here are the detailed specifications for the H2-8.6K-S4-US model:
Inverter
AC nominal power: 8600 W at 240 Vac
Rated AC current: 35.8 A at 240 Vac
Rated output voltage: 120/240 V
Surge AC power: 10320 VA for 10 seconds
Rated output frequency: 60 Hz
Maximum efficiency: 97.6%
Solar (PV input)
Maximum PV array power (Wp): 12900 W at STC (Standard Test Conditions)
Maximum DC voltage: 600 V
MPPT voltage range: 90–550 V
Nominal DC voltage: 360 V
Number of MPPTs: 4
Maximum DC input current: 16 A per MPPT
PV strings per MPPT: 1 per MPPT
 Battery
 Supported battery type: LiFePO4
Compatible batteries: UL9540 certified with Discover H2 B2-HV series high-voltage batteries.
Battery voltage range: 85–450 V
Maximum charging/discharging current: 50 A
Scalable storage: Supports up to four parallel stacks of B2 batteries for a total of 87.6 kWh per inverter.
 Physical and environmental
 Weight: 71 lbs (32 kg)
Dimensions: 27.2 x 19.3 x 7.8 inches (690 x 490 x 198 mm)
Mounting: Can be mounted on a wall or the ground.
Ingress protection: NEMA 4x (IP65) rated for outdoor installation.
Features and benefits
Backup power: Provides uninterrupted power by seamlessly switching to battery power during a grid outage.
Grid-tied and off-grid support: Flexible for various setups, including grid-tied systems that use the grid for backup and off-grid systems that rely solely on solar and batteries.
Scalable design: Can be paralleled with up to four other inverters to reach a total power output of 48 kW.
 Smart monitoring: Allows for remote monitoring and firmware upgrades via the Discover Energy Management App.
 AC coupling: Compatible with existing solar PV systems for easy integration.
Built-in safety: Includes an integrated AFCI (Arc Fault Circuit Interrupter) and RSD (Rapid Shutdown) protection.
