The product matching your query is the Discover Energy Systems H2-7.6K-S3-US H2 HV Split Phase Hybrid Inverter. This model features a 7600 Watt AC output and a high-voltage, wide-ranging 90–550 VDC MPPT input, with a maximum PV array power of 11,400 Watts.
Key specifications
According to NAZ Solar Electric and Discover Energy Systems' own documentation, here are the key specifications for the H2-7.6K-S3-US inverter:
PV input (DC)
Max PV array power: 11,400 Watts
MPPT voltage range: 90–550 VDC
Number of MPPTs: 3
Max DC input voltage: 600 V
Nominal DC voltage: 360 V
Max DC input current: 16A per MPPT
Battery
Compatible battery type: LiFePO4
Battery voltage range: 85–450 V
Max charging/discharging current: 50A
AC output
Nominal AC output power: 7,600W at 240VAC
Rated output voltage: 120/240V, split-phase
Rated frequency: 60Hz
Surge AC power: 9,120VA for 10 seconds
General
Maximum efficiency: 97.6%
Dimensions (HxWxD): 27.2" x 19.3" x 7.8" (690 x 490 x 198 mm)
Weight: 71 lbs (32 kg)
Warranty: 10 years
Features and applications
The Discover Energy Systems H2-7.6K-S3-US is a versatile solution for residential and small commercial properties.
Operating modes: It is suitable for both grid-tied applications, where it can feed excess energy back to the grid, and off-grid scenarios, where it uses stored battery power during outages or in remote locations.
High-voltage battery compatibility: It is designed to work with high-voltage battery systems, like Discover's own Helios ESS battery line, allowing for more efficient power management.
Performance optimization: The inverter's advanced Maximum Power Point Tracking (MPPT) technology ensures that solar panels operate at their peak efficiency, regardless of weather conditions.
Expandable power: It can be installed in parallel with up to four other inverters, allowing you to create a system with up to 48.0 kW of power.
AC coupling: The unit supports AC coupling with existing solar PV systems, providing a way to add battery backup to an existing setup.
Smart monitoring: A user-friendly interface and remote monitoring capabilities allow for real-time tracking and management of the system's performance.
