The product matching the description is the Discover Energy Systems H2-10K-S4-US H2 HV Split Phase Hybrid Inverter. It is a 10 kW hybrid inverter designed for residential and small commercial solar installations.
Key product features
Integrated power management: The H2-10K-S4-US seamlessly combines solar energy, battery storage, and grid power to optimize energy usage for both on-grid and off-grid scenarios.
High-voltage battery support: This inverter is compatible with Discover Energy Systems' high-voltage (HV) battery stacks, with UL9540 certification for the full system.
Advanced MPPT technology: The inverter's built-in Maximum Power Point Tracking (MPPT) maximizes the efficiency of your solar panels by dynamically adjusting to their optimal power output.
120/240V split-phase output: The split-phase design provides a flexible 120/240V output, which is standard for most residential and commercial electrical systems.
Scalable system: Multiple H2 inverters can be paralleled to increase the overall system capacity up to 48.0 kW.
Safety features: The inverter includes multiple safety features, such as an integrated AC short-circuit, overload, and over-temperature protection, as well as an Integrated AFCI and Rapid Shutdown (RSD).
User-friendly monitoring: The system allows for remote monitoring, enabling easy management and real-time tracking of performance.
Additional specifications
According to the H2 Series documentation from Discover Energy Systems:
Maximum PV Array Power (@STC): 18,000 Wp
MPPT Voltage Range: 90–550 VDC
Battery Voltage Range: 85–450 V
Maximum Charging/Discharging Current: 50 A
Max Efficiency: 97.6%
CEC Efficiency: 97%
Dimensions: 27.2 x 19.3 x 7.8 inches
Weight: 71 lbs
